ZLA-25L Semi-automatic Auger filling machine
Descriptive abstract
This type can do dosing and filling work. Due to the special professional design, so it is suitable to the fluidic or low-fluidity materials, like coffee powder, wheat flour, condiment, solid drink, veterinary drugs, dextrose, pharmaceuticals, powder additive, talcum powder, agriculture pesticide, dyestuff, and so on.
Caratteristiche principali
Stainless steel structure；Quick disconnecting or split hopper could be washed easily without tools.
Servo motor drive screw.
PLC & touch screen make it be easy of operation.
La retroazione del peso e il tracciato delle proporzioni eliminano la carenza di peso variabile imballato per varie proporzioni di materiale diverso.
Save the parameter of different filling weight for different materials. To save 10 sets at most
Replacing the auger parts, it is suitable for material from super thin powder to granule.
Main Technical DatUN
| Hopper | Quick disconnecting hopper 25L |
| Peso dell'imballaggio | 10 - 1000g |
| Precisione dell'imballaggio | ≤ 100g,≤±2%; 100 – 500g, ≤±1%; ≥500g,≤±0.5% |
| Velocità di riempimento | 5 – 20 times per min |
| Alimentazione elettrica | 3P AC208-415V 50/60Hz |
| Potere totale | 2.25Kw |
| Peso totale | 350kg |
| Overall Dimensions | 1205×1010×2174mm |
